Material Grade: 40Cr;
Quality Level: 12.9, 10.9, 8.8, 6.8, 4.8 Grade
Sizes:M48;
Specification: M48 x 180, M48 x 210, M48 x 330, M48 x 370, M48 x 390,M48 x 600, M48 x 700, M48 x 900, M48 x 1080
Bolt-head Shape: oval head, square head,ellipse head
Production Process:Heat-treated, High Strength
Service Life Guarantee: 12 months under normal working condition
Application: Bolt Units for SAG Mill dia.7.39m
Destination: Export to Russia,Australia,Finland
Special Features:
1. The high strength bolts have been widely used in large ball mills up to dia.12-meter mills.
2. The high strength screws can be reliably used in small,middle and large cement mills,coal mils and mine mills.
3. The high strength bolts have been properly heat-treated to achieve better mechanical properties.
4. The standard bolt units include one rubber ring,concave washer,spring washer and nut.
Specification For Bolt Units & Mill Liner Bolt Units & Bolt Nuts & Spring Washers & Flat Washers(M48 Bolts)
| - | Weight (kg/1000pc) | |
| Size | Without Nuts | With Nuts |
| M48*150 | 3005 | 3962 |
| M48*160 | 3147 | 4104 |
| M48*170 | 3289 | 4246 |
| M48*180 | 3431 | 4388 |
| M48*190 | 3573 | 4530 |
| M48*200 | 3715 | 4672 |
| M48*210 | 3857 | 4814 |
| M48*220 | 3999 | 4956 |
| M48*240 | 4141 | 5098 |
| M48*250 | 4432 | 5389 |
| M48*260 | 4574 | 5531 |
| M48*280 | 4858 | 5815 |
